HOIN - 2 inch Bluetoot+USB Mini smallest thermal receipt printer 58 mm mini ticket printer 58mm Desktop Thermal Printer
58MM Big Gear Thermal Receipt Printer
●Large motor, gear movement
●130 mm / s ultra high print speed
●The exquisite fashion design
●Support 1D,2D bar code printing
●Large paper warehouse design, the perfect support 83MM large diameter rolls
●support GB18030 big font
●support multi language print
●support small font print
Technologies matter a lot in the manufacturing process of the product. By applying technology, we have successfully upgraded the product.It is popular in the application scenario(s) of Printers now. Technological innovation is the cornerstone of product quality. For product inquiries, technical support, and other questions, you can reach us in any way stated on our 'Contact Us' page.
| Private Mold: | Yes | Products Status: | Stock |
| Type: | Thermal POS receipt Printer | Style: | Black and white |
| Use: | Thermal POS receipt Printer | Interface Type: | Bluetooth+USB |
| Max Paper Size: | 58mm | Black Print Speed: | 130mm/s |
| Max. Resolution: | 384 Dots/line | Brand Name: | Hoin |
| Model Number: | HOP-E58 | Place of Origin: | Guangdong, China |
| Warranty(Year): | 1-Year | After-sales Service: | Others, Call Center and on-line Technical Support, Onsite Training and Inspection |
| Printer name: | 58mm Thermal POS Receipt Printer | Effective Printing Width: | 58mm |
| Resolution: | 384dots/Line(8dots/mm,203dpi) | Interface: | USB+Bluetooth |
| paper width: | 57.5±0.5mm | paper thickness: | ≤0.12mm |
| paper Diameter: | ≤80mm | Print Head Life: | 100KM(print density≤12.5) |
| Dimension: | 180*115*127mm | Weight: | 750g |
| Certification: | FCC, ce, RoHS, BIS（ISI）, CB |
2 inch the smallest thermal receipt printer 58 mm mini ticket printer
Items | Parameters | |
Print parameters | Printing Method | Thermal Line |
Printing Method | 48MM | |
Resolution | 384dots/Line(8dots/mm,203dpi) | |
Printing Speed | 130mm/Second | |
Interface Type | USB+Bluetooth | |
Line Spacing | 3.75 mm(Can adjust line spacing by command) | |
Line | Font A-32Lines/Font B-42 Lines/Simple/Traditional Chinese-16 Lines | |
Character | Standard GB18030 simplified / traditional Chinese Fonts | |
Character Size | ANKcharacter,Font A:1.5×3.0mm(12×24Dots) | |
Bar code Character | Extended character set | PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew/EastEurope/Iran/WPC1252/PC866/PC852/PC858/IranII/Latvian/Arabic/PT151,1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/(Latvian)/(PC1001)/(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai) |
Bar code | 1D bar code:UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/ 2D bar code:QRCODE | |
Graphics printing | Graphics printing | Supports bitmap download and print
|
Paper | Type | Thermal Paper |
Width | 57.5±0.5mm | |
Diameter | ≤83mm | |
Feed Method | Easy feed(Clameshell feed) | |
Print commands | Commands | ESC/POS |
Power | Power Adaptor | Input:AC 110V/220V,50~60Hz Output:DC 12V/2A |
Casher Drawer output | DC 12V/1A | |
Buffer | Input Buffer |
|
NV Flash |
| |
physical characteristics | Weight | 0.75kgs |
Dimension | 180*115*127mm | |
Environment | Working | Temp:5 ~ 45℃, Humidity:10 ~ 80% |
| Storage | Temp:-10 ~ 50℃ ,Humidity:10 ~ 90%(No dew) |
Reliability parameter | Print Head Life | 100KM(print density≤12.5) |
| Cutter Life | 1000,000times |
We are a professional themal printer manufacture in shenzhen which can provide one package services from designing,R&D,production,logo printing,packaging to shipping.
Most of our thermal receipt printers are CE, CFF, RoHS,BIS,CB,CCC certified. Our products are Hot sale all over the world. Thermal Printers have been widely used in the shopping mall,warehousing,retail, telecommunications, medical, tax, police, government, logistics and other industries.
