HOIN | Latest thermal label printer Company
With strong R&D strength and production capabilities, HOIN now has become a professional manufacturer and reliable supplier in the industry. All our products including thermal label printer are manufactured based on the strict quality management system and international standards. thermal label printer Today, HOIN ranks the top as a professional and experienced supplier in the industry. We can design, develop, manufacture, and sell different series of products on our own combining the efforts and wisdom of all our staff. Also, we are responsible for offering a wide range of services for customers including technical support and prompt Q&A services. You may discover more about our new product thermal label printer and our company by directly contacting us.At HOIN, our innovative team of designers is behind the captivating design of our products. We carefully choose colors, fonts, and shapes to make our brand stand out. Trust us to provide you with unparalleled design.
Shenzhen Hoin Electronic Technology Co conforms to the development trend of the industry, integrates internal superior resources, adopts the industry's cutting-edge manufacturing technology and production technology, and successfully creates Shipping Express Waybill Label Printer 3 Inch Direct Thermal Label Printer Machine Label Printer for POS Thermal Line 80mm Hoin with excellent performance and reliable quality. Technological innovation is an important factor for products to form core competitiveness and maintain competitive advantage. Shenzhen Hoin Electronic Technology Co has always insisted on winning by "quality", and has won wide recognition and praise from many companies with high-quality services.
| Products Status: | Stock | Type: | Label Printer |
| Style: | Black and white | Use: | Label Printer for POS |
| Interface Type: | USB | Max Paper Size: | 80mm |
| Black Print Speed: | 127 mm (5") / s, | Color Print Speed: | not support |
| Max. Resolution: | 203 DPI | Brand Name: | Hoin |
| Model Number: | HOP-HL80 | Place of Origin: | Guangdong, China |
| Warranty(Year): | 1-Year | After-sales Service: | Others, Call Center and on-line Technical Support |
| Printing Method: | Thermal Line | Command: | TSPL-EZ emulation,ZPL,EPL,DPL |
| Resolution: | 203 DPI | Interface: | USB |
| barcode: | 1D,2D | paper width: | 76mm (3") |
| Print Length(Max): | 1770 mm (70") | Printer Size: | 225 mm (D) x151 mm (W) x151 mm (H) |
| Label Paper Roll Diameter: | 25-120mm | Paper type: | Adhesive Sticker |
| Certification: | FCC, ce, RoHS, BIS（ISI）, CB |
Shipping Express Waybill Label Printer 3 inch Direct Thermal Label Printer Machine 203dpi USB or USB+Bluetooth HOP-HL80
HOP-HL80
Thermal Label Printer
80mm Thermal Label Barcode Printer
*Command:TSPL-EZ emmulation ,ZPL,EPL,DPL
*Paper Width:20mm-80mm Paper
*Diameter Paper roll:25-120mm
*Reslution:203DPI
*Length:1770mm(70inch Max)
*Support 1D 2D bar code printing
*Support Serial Sequence
*Support Dlabel, Nicelabel, Bartender etc software
Data sheet:
|
Resolution |
203 DPI |
|
|
Print Method |
Thermal Print |
|
|
Print Speed(Max) |
127 mm (5") / s, |
|
|
Print Width(Max) |
76mm (3”) |
|
|
Print Length(Max) |
1770mm(70") |
|
|
Printer Size |
225 mm (D) x151 mm (W) x151 mm (H) |
|
|
Printer Weight |
1.08kg |
|
|
Label Paper Roll Diameter |
25-120mm |
|
|
Paper Direction |
Paper Up |
|
|
Processor |
32-bit CPU |
|
|
Memory |
n 8M Flash memory |
|
|
Interface |
USB (Standard) Bluetooth (Optional) |
|
|
Power |
Adaptor n Input: AC 100-240V n Output: DC 24V-2.5A |
|
|
User Indicator |
Standard Model n 2 Press Buttons n 1 LED Blue Light,1 LED Red Light |
|
|
Sensor |
n Gap Sensor n Cover Opening Sensor n Printer Head Temperature Sensor |
|
|
Paper Type |
Thermal paper, Thermal adhesive paper, etc |
|
|
Media Type |
Continuous,Gap |
|
|
Media Width |
20 mm ~ 82 mm |
|
|
Media Thickness |
0.06 mm ~ 0.25 mm |
|
|
Label Length |
10 mm ~ 1770 mm |
|
Bar Code |
1D bar code Code128 subsets A.B.C,Code128UCC, EAN128, Interleave 2 of 5,Code 39,Code 93, EAN-13, EAN-8, Codabar, POSTNET, UPC-A, UPC-E, EAN and UPC 2(5) digits, MSI, PLESSEY, China Post, ITF14, EAN14, Code 11, TELPEN, PLANET, Code 49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS 2D bar code CODABLOCK F mode, DataMatrix, Maxicode, PDF-417, Aztec, MicroPDF417, QR code, RSS Barcode (GS1 Databar) |
||
|
Rotation on font and Bar code |
0°, 90°, 180°, 270° |
||
|
Command |
TSPL-EZ emulation |
||
|
Environment |
Operation Environment: -10 ~ 50 °C (14 ~ 122 °F), Humidity:10 ~ 90% No condensing Storage Environment: -40 ~ 60 °C (-40 ~ 140 °F), Humidity:10 ~ 90% No condensing |
||
|
Accessories |
n Windows Volume label editing software, driver and operation manual CD n Fast installation guide n Power adaptor n Power cable n USB cable |
||
|
Reliability |
n One year warranty n Printer head 50KM or One year warranty. Depends on which reach first. n Printer roller 50KM or One year warranty. Depends on which reach first. |
||
We are a professional themal printer manufacture in shenzhen which can provide one package services from designing,R&D,production,logo printing,packaging to shipping.
Most of our thermal receipt printers are CE, CFF, RoHS,BIS,CB,CCC certified. Our products are Hot sale all over the world. Thermal Printers have been widely used in the shopping mall,warehousing,retail, telecommunications, medical, tax, police, government, logistics and other industries.
HOIN 7 Biggest Features to sell printers all over the world:
1.Hoin is the most professional Thermal Printer Manufacturer in Shenzhen China
2.All engineers with more than 10 years experiences in thermal printers
3.OEM,ODM available
4.Free software,SDK available
5.All printers with 1 year warranty,all life free maintenance
6.Most printers with CE,FCC,ROHS,CCC,CB,BIS certification.
7.High quality,fast delivery,sample 3-5 days,bulk order 15days.
