HOIN - BIS certified 80mm Thermal Bill Printer HOP-HL58 with USB/LAN/Serial interface optional 80mm POS system printer
Classical and Economical Auto Cutter 80MM thermal printer
●print speed: 260 mm / sec
●Support 1D,2D bar code printing
●Excellent waterproof, dustproof, anti oil design
●The standard GB18030 Font
●The printer monitoring function, to avoid losing any bills
●support multi language print
●support small font print
●support wall hang function
After a long time of development,Shenzhen Hoin Electronic Technology Co has successfully launched BIS certified 80mm Thermal Bill Printer HOP-HL58 with USB/LAN/Serial interface optional. BIS certified 80mm Thermal Bill Printer HOP-HL58 with USB/LAN/Serial interface optional is made available in a varied range of specifications. Research and development are the pillars on which the future of our company rests. Shenzhen Hoin Electronic Technology Co will put more emphasis on improving our R&D strength in the future for developing more creative and competitive new products.
| Products Status: | Stock | Type: | Thermal Receipt Printer |
| Style: | Black and white | Use: | Thermal POS Receipt Printer |
| Interface Type: | USB | Max Paper Size: | 80mm |
| Black Print Speed: | 260mm/sec | Color Print Speed: | not support |
| Max. Resolution: | 576 Dots/line | Brand Name: | Hoin |
| Model Number: | HOP-HL58 | Place of Origin: | Guangdong, China |
| Warranty(Year): | 1-Year | After-sales Service: | Others, Call Center and on-line Technical Support, Onsite Training and Inspection |
| Software development kit (SDK): | Yes | Printing Method: | Thermal Line |
| Effective Printing Width: | 72mm | Resolution: | 576 Dots/Line or 512 Dots/Line(8dots/mm,203dpi) |
| Interface: | USB | barcode: | 1D 2D |
| paper width: | 79.5±0.5mm | paper thickness: | ≤0.12mm |
| paper Diameter: | ≤80mm | Instructions: | ESC/POS |
| Print Head Life: | 100KM(print density≤12.5) | Certification: | FCC, ce, RoHS, BIS（ISI） |
BIS certified 80mm Thermal Bill Printer HOP-HL58 with USB/LAN/Serial interface optional
Items | Parameters | |
Print parameters | Printing Method | Thermal Line |
Printing width | 72mm | |
Resolution | 576 Dots/Line Or 512 Dots/Line(8dots/mm,203dpi) | |
Printing Speed | 220mm/s | |
Interface | USB | |
Line Space | 3.75mm(Can adjust line space by command) | |
Line No. | Font A-32 Lines/Font B-42 Lines/Simple,traditional Chinese-16 Lines | |
Character | standard GB18030 simplified / traditional Chinese | |
Character Size | ANK character,Font A:1.5×3.0mm(12×24 dots) | |
Bar code Character | Extended character set | PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew/EastEurope/Iran/WPC1252/PC866/PC852/PC858/IranII/Latvian/Arabic/PT151,1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/(Latvian)/(PC1001)/(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai) |
Bar code | 1D Bar code:UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/
| |
Graphics printing | Graphics printing | Supports bitmap download and print ( each bitmap size Max.20K)
|
Cutter | Cutter Function | Full cut/Half cut |
Paper | Type | Thermal |
Width | 79.5±0.5mm | |
Diameter | ≤80mm | |
Feed method | Easy feed(Clameshell feed) | |
Special function | Oil Shield | Support |
Bills not taken detect and remind | Support | |
Tibet line slot | Support | |
Bulit in loudspeaker | Support | |
Print Commands | Commands | ESC/POS |
Power | Power Adaptor
| Input:AC 110V/220V,50~60Hz |
Output:DC 24V/2.5A | ||
Cash Drawer output | DC 24V/1A | |
Buffer | Input Buffer | 2048K bytes |
NV Flash | 256K bytes | |
physical characteristics | Weight |
1.15KG |
Dimension |
195*140*148(MM) | |
Environment | Working | Temp:5 ~ 45℃, Humidity:10 ~ 80% |
Storage | Temp:-10 ~ 50℃ ,Humidity:10 ~ 90%(No dew) | |
Reliability parameter | Print Head Life | 100KM(print density≤12.5) |
Cutter Life | 1000,000times | |
Software | Driver | Android,IOS,Linux,Win2000,Win2003,WinXP,Win7,Win8,Win8.1,Win10 |
Shenzhen Hoin Electronic Technology Co.,Ltd is a high tech enterprise specialized in thermal mini receipt printer,thermal barcode label printer,shipping label printer,panel printer, kiosk printer and scanner reader. We can offer one-stop services from R&D, printer main board design,plastic molding, materials assembling, production, packing, testing,sales,delivery to after-sales services.
Most of our thermal receipt printers are CE, CFF, RoHS,BIS,CB,CCC certified. Our products are Hot sale all over the world. Thermal Printers have been widely used in the express shipping,supermarket,shopping mall,warehousing,retail, telecommunications, medical, tax, police, government,logistics and other industries.
HOIN 7 Biggest Features to sell printers all over the world:
1.Hoin is the most professional Thermal Printer Manufacturer in Shenzhen China
2.All engineers with more than 10 years experiences in thermal printers
3.OEM,ODM available
4.Free software,SDK available
5.All printers with 1 year warranty,all life free maintenance
6.Most printers with CE,FCC,ROHS,CCC,CB,BIS certification.
7.High quality,fast delivery,sample 1-3 days,bulk order 6-15days.
Certifications:
1, Are you a manufacture?And What is the MOQ?
We are the professional thermal receipt and label printer manufacturer with full production line. Sample printer 1-2pcs are also welcomed.
2, Can you customize or design the product? Can you add my own Logo?
OEM and ODM are available, We have our own R&D team and our engineers have been in POS Printing field for more than 10 years. MOQ:1000pcs, we can add your logo for free.
3, What languages can you support? Besides,what operation system can you support?
Our printer can support English, Spanish,Korea,France,Portuguese,Arabic,Russian,etc 70 languages. We can support Android,IOS,Linux,Mac book, Win2000,Win2003,WinXP,Win7,Win8, Win8.1,Win10,Win11,etc.
4, What's your deliver time?
For sample,1-3 days; bulk order usually 7-15days,depends on quantity.
5, Can you provide drive and latest software?
Yes. All the Android/IOS SDK, Windows 58mm and 80mm driver, and Android/IOS testing app are available for free. Pls check:www.hoinprinter.com/download/39.html
